• USB 2.0 cable for charging and data transfer
  • Supports USB Power Delivery
  • Compact connector that is approximately 40% smaller than conventional products (compared to our company)
  • Certified Hi-Speed ​​USB (USB2.0) regular certified product
  • The cable can be inserted regardless of the front or back
  • High-speed data transfer up to 480Mbps
  • Use flame-retardant material
  • Double shielded cable to protect signals from external noise interference
  • Gold-plated pin that is resistant to rust and suppresses signal deterioration


Connector shape USB Type-C(TM) male to USB Type-C(TM) male
Compatible models PCs with USB Type-C(TM) terminals and peripheral devices with USB Type-C(TM) terminals
Cable length 1m, 2m
Cable thickness 3.8mm
Standard USB2.0 standard regular certification product
Supported transfer speed Maximum 480Mbps *Theoretical value
Power delivery compatible Yes
Correspondence wattage Max 100W
Supports ALT mode No
Plug plating specification Gold plated pins
Shield method Double shield
Twisted pair cable (communication line) Yes
Color Black
Qty available:0
USB 2.0 Cable Type-C to Type-C U2C-CC5PC Series
